Burkert Angle type Pneumatic Actuated Valve, 16 bar 2 in | 001401

Name: Burkert Angle type Pneumatic Actuated Valve, 16 bar 2 in | 001401
SKU: 9803-618
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 6 pcs

Mfr. Part No: 001401

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 9803-618 Categories: Burkert, Pneumatic Actuated Valves

Description

Specifications

Attribute	Value
Brand	Burkert
Product Type	Pneumatic Actuated Valve
Inlet Connection Type	Threaded
Valve Type	Angle
Inlet Port Size	2 in
Default Valve Position	NC
Return Type	Spring
Outlet Connection Type	Threaded
Outlet Port Size	2 in
Maximum Operating Pressure	16 bar
Valve Material	Stainless Steel
Minimum Operating Temperature	-10°C
Outlet Thread Standard	G
Maximum Operating Temperature	60°C
Standards/Approvals	No

Product Details

Series 2000 Two-way, Angle Seat Valve – Stainless Steel Body

2/2- way pneumatically operated angle seat valves. Available in both NO (Normally Open) and NC (Normally Closed) configurations and with the flow direction above or below the seat

For use with neutral gases, air, steam, water and oil. (also aggressive fluids with stainless steel body)

Polyamide actuator casing and PTFE seal material

Self-adjusting spindle packing glands; wiper seal; intermediate relief

High flow rates from compact designs

For use with neutral gases, air, steam, water, oil and aggressive fluids

Ambient temperature range: –10 to +60°C

Media temperature range: –10 to +180°C
