Burkert Angle type Pneumatic Actuated Valve, 16 bar 3/4 in | 178664

The Burkert pneumatic valve with angle seat ¾in G connection has normally closed (NC) configuration and is made of cast stainless steel for maximum operating pressure of 16bar. It has 2 //2-way configuration with the under-seat flow for liquids. This anti-water hammer valve employs live loaded packing and an N-seal piston actuator, all in an application proven rugged compact envelope.

Ambient temperature ranging between –10°C and 60°C

Flow rate is 9m³/h

High flow rates because of compact design

Intermediate relief

Media temperature ranging between –10°C and 180°C

Orifice is 20mm

Polyamide actuator casing and PTFE seal material

Self-adjusting spindle packing glands

Wiper seal

GL approved

SIL approved
