Burkert Solenoid Valve 235325, 2 Port, Universal, 24 V dc 3.18 mm, 3.18 mm | 235325
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: 235325
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Burkert |
| Product Type | Solenoid Valve |
| Supply Voltage | 24 V dc |
| Number of Ports | 2 |
| Inlet Port Size | 3.18 mm |
| Default Valve Position | Universal |
| Outlet Port Size | 3.18 mm |
| Orifice Diameter | 3mm |
| Inlet Port Gender | Female |
| Series | 235 |
| Body Material | Polyetheretherketone |
| Application | Liquid |
| Outlet Port Gender | Female |
| Maximum Operating Pressure | 2 bar |
| Minimum Operating Temperature | 10°C |
| Maximum Operating Temperature | 55°C |
| Standards/Approvals | No |
| Servo Assist | No |
| Hazardous Area Certification | No |
| Flow Factor Kv | 0.17m³/h |
| Maximum Closing Time | 25ms |
| Maximum Opening Time | 25ms |
Product Details
Burkert Solenoid Valve
The Burkert 235 series 1/8inG female solenoid valve has a supply voltage of 24VDC. This 2-port valve is made of PEEK material with an isolating diaphragm for high chemical resistance. It is used to control aggressive fluids and gases in analytical medical applications, food industry and chemical industry for dosing, filling and mixing application.
Features and Benefits
Flow factor (Kv) is 0.17m³/h
Maximum working pressure is 2bar
Power consumption is 5W
Ultra-compact design of 22 mm with orifices up to DN 3.0
Back pressure tightness via rocker principle
Minimal internal volume with excellent clean ability
Operating temperature ranges between -10°C and 55°C
Certifications
IP54 rated
