Carling Technologies V, 3 Position DPDT Rotary Switch, 15 (24 V) A, Quick Connect | RV26B2VJDC-K4C
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: RV26B2VJDC-K4C
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Carling Technologies |
| Contact Configuration | DPDT |
| Product Type | Rotary Switch |
| Series | V |
| Switch Operation | Momentary, Maintained |
| Switch Contact Current | 15 (24 V) A |
| Number of Positions | 3 |
| Housing Material | Polybutylene Terephthalate |
| Depth | 60mm |
| Number of Poles | 10 |
| Width | 24.38 mm |
| Maximum DC Voltage | 24V |
| Mount Type | Front Panel Snap-In |
| Switch Configuration | On-Off Highway |
| Terminal Type | Quick Connect |
| Diameter | 35.56 mm |
| Standards/Approvals | RoHS |
| IP Rating | IP67 |
| Height | 39.37mm |
| Mechanical Life | 100000Cycles |
| Illuminated | Yes |
| Angle of Throw | 60 ° |
| Actuator Colour | Black |
Product Details
Carling V Series Rotary Switches
Carling Technologies V-Series Contura Rotary Switch offer high performance and reliability, leveraging the features of the popular V-series Contura Rocker Switches.
Available in maintained and momentary circuit options, the V-Series rotary switches feature a sturdy knob construction, up to three separate LEDs, and is designed to fit in an industry standard panel opening.
Accommodates up to three separate LEDs
Patented mechanism translates rotary into linear motion
Secondary CAM for definitive detent positions
PC Board supports LED and surface mount resistors
IP67 sealing protection above panel
Common terminal & circuit functionality with V-Series Rocker switches
