Carlo Gavazzi Solid State Relay, 25 A Load, Panel Mount, 530 V ac Load, 32 V dc Control | RS1A48D25
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: RS1A48D25
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Carlo Gavazzi |
| Maximum Load Current | 25 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 530 V ac |
| Minimum Load Voltage | 42 V ac |
| Minimum Control Voltage | 4 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero |
| Control Voltage Range | 4 → 32 V dc |
| Minimum Load Current | 150 mA |
| Terminal Type | Screw |
| Contact Configuration | SPST |
| Maximum Turn On Time | 1 s |
| Load Voltage Range | 42 → 530V ac |
| Dimensions | 44.8 x 58.2 x 28.8mm |
| Length | 44.8mm |
| Off State Leakage Current | <3 mA |
| Height | 28.8mm |
| Operating Temperature Range | -40 → +80°C |
| Depth | 58.2mm |
Product Details
Carlo Gavazzi Zero-Switching Solid State Relay
Solid State relays with integral heatsink offer the user an excellent alternative to convensional relays. Comes equipped with an IP20 touch-safe cover can be easily detached to accomodate Ring Terminal connections and then be added back onto the relay. Integrated cooling fans are supplied with higher-rated relays, such as 75&90A variants
Easily mountable onto DIN rail
Zero-switching suitable for use with Resistive loads and motors
Integrated Snubber network
LED status indication
AC and/or DC control voltage to ensure your application is covered
70A maximum output current
Zero-switching suitable for use with Resistive loads and motors
Integrated Snubber network
LED status indication
AC and/or DC control voltage to ensure your application is covered
70A maximum output current
Zero Voltage Relays
Note
Temperature can affect current rating; please consult the data sheet for potential derating.
