Celduc XK Series Solid State Interface Relay, 30 V Control, 2 A Load, DIN Rail Mount | XKD10120
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: XKD10120
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Celduc |
| Maximum Control Voltage | 30 V |
| Maximum Load Current | 2 A |
| Mounting Type | DIN Rail |
| Maximum Load Voltage | 220 V |
| Control Voltage Range | 5 → 30 V dc |
| Switching Type | DC |
| Load Voltage Range | 2 → 220V |
| Terminal Type | Screw |
| Number of Poles | 1 |
| Output Device | Bipolar Transistor |
| Depth | 17.2mm |
| Minimum Load Current | 3 mA |
| Series | XK |
| Length | 76.4mm |
| Height | 53mm |
| Dimensions | 76.4 x 17.2 x 53mm |
| Range | XK |
| Minimum Operating Temperature | -40°C |
| Standards Met | CE, EAC |
| Special Features | Control Visualization By LED. |
| Maximum Operating Temperature | +90°C |
| Maximum Turn On Time | 20ms |
| Manufacturer Part No. | XKD10120 |
| Operating Temperature Range | -40 → +90°C |
Product Details
Non-pull-out vertical relays for DIN rail
Non-pull-out vertical relays for DIN Rail
Relays for controlling all types of loads.
These relays feature a high level of immunity to outside interference, a low off-state leakage current and a surge suppressor.
Relays for controlling all types of loads.
These relays feature a high level of immunity to outside interference, a low off-state leakage current and a surge suppressor.
