Chauvin Arnoux 1 % Sensor 3000 A 1000V | P01120600
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: P01120600
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Chauvin Arnoux |
| Product Type | Sensor |
| Current Accuracy | 1 % |
| Voltage Accuracy | 1.5% rgd |
| Maximum Current Measurement | 3000A |
| Maximum Voltage Measurement | 1000V |
| Minimum Current Measurement | 0.5A |
| Minimum Voltage | 3V |
| Length | 350mm |
| Width | 110 mm |
| Better World Claim | Renewable Energy Solution |
| Better World Product | Yes |
| Minimum Operating Temperature | 0°C |
| Standards/Approvals | CEI64-8, CEI82-25, EN60891, EN60904-5, EN61557-2, EN61557-4, EN61724, EN62446 |
| Maximum Operating Temperature | 40°C |
Product Details
MiniFlex MA500 3kA AC sensor for photovoltaic tester FTV500
MiniFlex MA500 3 kA AC current flexible sensor for FTV500 photovoltaic tester
Current range : 0,5 à 3 000 A c.a.
Dimensions : Ø 5.5 mm
Clamping diameter: Ø 110 mm
Sensor length: 350 mm
Weight: 60 g
Connection: with 3-metre cable and FRB01 connector
Electrical safety: EN61010-1 or EN BS 61010-1, EN61010-2-032 or EN BS 61010-2-032, Cat.III 1 000 V, Cat.IV 600 V
Accessory used with the FTV500 Photovoltaic Tester (274-1323)
