Chauvin Arnoux CA 5001 Handheld Multimeter, 1000 V ac Max 1000 V | P01196521E

The CA 5001 analogue multimeter has been designed to meet all the measurements required by electricians. With its shockproof case and folding multi-purpose stand, you can use it both outdoors on construction sites and indoors (in the laboratory).

Its analogue display, with anti-parallax mirror, is ideal for simple, fast and accurate reading.

Two versions are available, and it also comes with a carrying case for protection and safe transport.

DC current : 5 ranges 50 μA / 5 mA / 50 mA / 500 mA / 5 A

AC current : 4 ranges 5 mA / 50 mA / 500 mA / 5 A

AC voltage : 5 ranges 10 V / 30 V / 100 V / 300 V / 1000 V

DC voltage : 8 ranges : 100 mV / 1 V / 3 V / 10 V / 30 V / 100 V / 300 V / 1000 V

Frequency : 10 Hz to 100 kHz

Resistance : 1MΩ

Continuity

dB scale : 0 to 22 dB

a set of silicon leads with straight banana plugs / angled banana plugs, a set of safety test probes and a 1.5 V LR6 battery.

CEI 61010-1, 600 V category III

– Kit of accessories for electricians P01295459Z / 212-2591

– Current measurement lead CMI214S P03295509 / 231-3654

– Set of 2 red/black moulded test probes P01295454Z / 226-1666

– Set of 2 red/black magnetized test probes P01103058Z / 229-6163

– Set of 2 red/black moulded silicone leads P01295452Z / 212-2585

Range of analogue multimeters for safe measurement of direct or alternating currents.

Shockproof case with a “Multistand” multi-purpose fold-away stand for use at worksites as well as in the lab.

Analogue display with anti-parallax mirror for voltage scales.

The C.A 5005 multimeter is supplied with an MN89 mini-clamp and “Voltest” function to test for voltage on resistance and continuity tests.

Two versions, available in a carry cases with steel hinges for safe storage, protection and transport.

AA alkaline batteries (stock no.: 591-225) also available separately from the catalogue.

IEC 61010-1, category III / 600 V (C.A 5001);

IEC 61010-1, category III / 1000 V (C.A 5005)
