Chauvin Arnoux CA 5231 Handheld Digital Multimeter True RMS | P01196731
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: P01196731
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Chauvin Arnoux |
| Product Type | Multimeter |
| Multimeter Type | Handheld |
| Model Number | CA 5231 |
| Display Type | Digital |
| Resistance Resolution | 100mΩ |
| Functions Measured | Capacitance, AC Current, Continuity, AC Voltage, Resistance, Diode, NCV (Non-contact Voltage), DC Voltage, Temperature, DC Current, Frequency |
| Maximum DC Voltage Measurement | 1000V |
| True RMS | Yes |
| DC Current Accuracy | ±2.5 % rdg + 12 Digits |
| AC Current Accuracy | ±2 % rdg + 3 Digits |
| AC Voltage Accuracy | ±2 % rdg + 3 Digits |
| DC Voltage Accuracy | ±0.2 % rdg + 2 Digits |
| AC Current Resolution | 0.1A ac |
| DC Voltage Resolution | 0.01 mV |
| DC Current Resolution | 0.1A dc |
| AC Voltage Resolution | 0.01mV ac |
| Maximum Frequency | 3kHz |
| Power Source | Battery |
| Minimum Operating Temperature | 0°C |
| Battery Life | 100h |
| Maximum Operating Temperature | 50°C |
| Standards/Approvals | No |
| Weight | 320g |
| Length | 75mm |
| Height | 155mm |
| Width | 75 mm |
| Safety Category Level | CAT III, CAT IV |
| Safety Category Voltage | 1000V |
| Calibrated | RSCAL |
| Battery Type | IEC 6LR61 |
Product Details
CA 5231 TRMS Portable Digital Multimeter from Chauvin Arnoux
The Chauvin Arnoux CA 5231 TRUE RMS multimeter meets the needs of every electrician. Compact and simple, it is extremely easy to read thanks to its large 6,000 counts backlit display + bar graph.
Built-in shock protection makes it resistant to knocks and drops.
The DMM CA 5231 has a non-contact voltage detection function, so the display lights up when it detects nearby voltage. Featuring a current clamp function, it measures currents up to 600 A A.C. in complete safety.
The CA 5231 multimeter is designed for general electrical measurements, allowing users to test AC/DC voltage, AC/DC current, resistance, continuity and diode tests.
CA 5231 digital multimeter key features
IP54
TRMS measurements
Large 6,000-counts backlit display (digit height: 8 mm)
61-segment bar graph
Compact case with integrated shock protection
Voltage a.c, d.c, a.c/d.c 1000 V
Current a;c, c;c, a.c/d.c
Non-contact voltage detection
Low impedance position on AC voltage
Audible diode/continuity test
HOLD function
Resistance : 60 MΩ
Delivered with
CA5231 digital multimeter supplied with 1 set of red/black test-probe leads, 1x 9 V alkaline battery, Operating instructions in 5 languages
Standards
600 V CAT IV/CAT III 1 000 V
Useful accessories
– Set of 2 red/black moulded PVC leads P01295451Z / 212-2583
– Set of 2 red/black crocodile wire grips P01102053Z / 229-6127
– Set of 2 red/black magnetized test probes P01103058Z / 229-6163
– Set of 2 red/black moulded silicone leads P01295452Z / 212-2585
