Chauvin Arnoux Current Clamp, AC Adapter, 3000 A AC Max | P01120057A
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: P01120057A
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Chauvin Arnoux |
| Product Type | Current Clamp |
| Adapter Type | AC |
| Maximum AC Current | 3000A |
| Accuracy | ±2 % |
| Maximum Conductor Size | 64 mm |
| Cable Length | 1.5mm |
| Connector Type | BNC |
| Battery Type | AA, Alkaline, LR6 |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | 50°C |
| Standards/Approvals | No |
| Safety Category Level | CAT IV |
| Safety Category Voltage | 300V |
Product Details
D38N Oscilloscope clamp for AC current
The D38N (insulated AC current probe) offers accurate AC current measurement and a voltage output in mV allowing direct readings on oscilloscopes.A switch with 3 positions on the handle can be used to select the ranges.The wide opening of the jaws means they can be used on cables and small busbars.
Current calibres:
1 A AC to 30 A AC (90 A peak)
1 A AC to 300 A AC (900 A peak)
1 A AC to 2400 A AC (9000 A peak)
(3000 A for temperature < 35°C)
Bandwidth:
10 Hz to 50 kHz (depending on current)
Max. jaw opening: 90 mm
Output: 2 m coaxial lead with insulated BNC plug
Standards
IEC 1010-1 and IEC 1010-2-032, 600 V category III pollution degree 2, 300 V category IV pollution degree 2
Supplied with
Operating manual.
