Chauvin Arnoux PEL112 Power & Energy Data Logger, Ethernet, IRD Server, USB, Wifi, 3V / 3I Input Channel(s) | P01157156
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: P01157156
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Chauvin Arnoux |
| Number of Input Channels | 3V / 3I |
| Model Number | PEL112 |
| Measurement Parameters | Current, Energy, Frequency, Harmonics, Power, Voltage |
| Sensor Type | Current, Voltage Sensors |
| Interface Type | Ethernet, IRD Server, USB, Wifi |
| Data Logger Type | Power & Energy |
| Maximum Voltage Measurement | 1000V |
| Power Source | Battery and Self-powered by Phase |
| IP Rating | IP54 |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | +50°C |
| Maximum Current Measurement | 10 000A |
| Includes | A PEL 112 is delivered with : 1 carrying bag, 4 voltage cables, 4 crocodile clips, 1 set of inserts/ rings, 1 SD card, 1 SD Card-USB adapter, 1 USB cable, PEL TRANSFER PC software & User’s Manual downloadable from our website, 1 Quick Start Guide. |
| Model Number p | PEL112 |
| Current Measurement Resolution | 1 mA |
| Battery Type | Rechargeable NiMH battery |
| Alarm | Yes |
| Best Voltage Measurement Accuracy | ± 0.2% R ± 0.2 V |
| Best Current Measurement Accuracy | ± 0,3% |
| Dimensions | 256 x 125 x 37mm |
| Number of Readings Per Channel | 5 readings / s |
Product Details
Part of the PEL 110 family (PEL 112, PEL 113, PEL 115), this power and energy logger is a Made In France product.
With no display, the PEL 112 has an extended operating temperature range down to -20°C, enabling it to be used in sub-zero environments such as cold stores.
Intuitive, compact and lightweight, the PEL 112 is easy to install without disconnecting the mains supply, in electrical cabinets or on distribution boards. Compatible with single-phase, two-phase and three-phase electrical installations, it offers a wide range of voltage and current measurements, and can be used with a variety of transducers to suit different conductors and the specifics of your applications.
The PEL 112 measures active (kW), reactive (kVAR) and apparent (kVA) power, as well as the energy consumed, with a high degree of accuracy.
It has an extended recording capacity for collecting data over long periods (SD card storage), as well as a sampling frequency that can be customised to suit your needs, enabling you to obtain detailed, accurate analysis.
Featuring advanced connectivity, USB, Ethernet and Wi-Fi wireless links, all data can be monitored in real time and retrieved locally or remotely for analysis and automatic report generation via the PEL Transfer software supplied with the device.
What’s more, a secure server means you can access your data from anywhere in the world!
A dedicated ANDROID application can also be used to check that the PEL 112 is working properly and to change its configuration.
Applications
- Voluntary or mandatory energy audits
- Diagnosis of electrical installations
- Optimising energy efficiency
- Identifying the causes of over-consumption
- Equipment monitoring
- Analysis of consumption, energy balance, energy savings
- Sizing electrical installations
- Compact magnetised case
- Extended operating temperature range to -20°C
- Communication via Wifi, LAN (Ethernet) and USB
- ANDROID application
- Self-powered by phase
- Recording over several months (SD card)
- Automatic recognition of sensor type
- 4 voltage inputs and 3 current inputs
- Wide measurement range
- Breakdown of energy losses
- Frequency, cos φ, tan Φ, PF
- Useful, active, reactive and apparent powers and energies,
- THD calculation for currents and voltages
