Crouzet CTR24 Counter, 8 Digit LCD, 260 V ac/dc | 87622070
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: 87622070
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Crouzet |
| Supply Voltage | 260 V ac/dc |
| Count Mode | Impulses |
| Display Type | LCD |
| Input Type | Voltage |
| Function | Counter |
| Connection Type | Screw |
| Reset Method | Manual, Signal |
| Number of Digits | 8 |
| Mounting Type | Panel Mount |
| Digit Height | 8 mm |
| Display Range | -9999999 → 99999999 |
| Measurement Range | -9999999 → 99999999 |
| Maximum Operating Temperature | +60°C |
| Minimum Operating Temperature | -10°C |
| Weight | 50g |
| Series | CTR24 |
Product Details
Crouzet Digital Counter
The Crouzet CTR24 series digital counter is an impulse, panel mounted device and powered by an internal lithium battery device. This counter has a voltage input and has an 8-digit LCD display. The display ranges between -9999999 and +99999999. It has the supply voltage rating of 260VAC/VDC.
Features and Benefits
Non-backlit
Reset on panel or external with inhibition option
Counting directions can be selected with input
Accessories for 50mm x 25mm cut-out
Panel cut out dimensions are 45mm x 22.2mm
Plug-in screw terminal connection
Operating temperature ranges between -10°C and 60°C
Reset on panel or external with inhibition option
Counting directions can be selected with input
Accessories for 50mm x 25mm cut-out
Panel cut out dimensions are 45mm x 22.2mm
Plug-in screw terminal connection
Operating temperature ranges between -10°C and 60°C
Applications
Industrial counting applications
Control and monitoring systems
Manufacturing assembly line
Control and monitoring systems
Manufacturing assembly line
Certifications
UL approved
CE certified
EN 61000-6-2 – EN 55011 class B
CE certified
EN 61000-6-2 – EN 55011 class B
