Crouzet CTR24 Counter, 8 Digit LCD, 3 → 30 V dc | 87622062
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: 87622062
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Crouzet |
| Supply Voltage | 3 → 30 V dc |
| Count Mode | Impulses |
| Display Type | LCD |
| Function | Counter |
| Input Type | Transistor |
| Connection Type | Screw |
| Reset Method | Manual, Signal |
| Number of Digits | 8 |
| Mounting Type | Panel Mount |
| Output / Interface | Transistor |
| Digit Height | 8 mm |
| Display Range | -9999999 → 99999999 |
| Maximum Operating Temperature | +60°C |
| Measurement Range | -9999999 → 99999999 |
| Minimum Operating Temperature | -10°C |
| Weight | 50g |
| Series | CTR24 |
Product Details
CTR24 LCD Impulse Counter Series
Display comprises of an 8-digit LCD with a digit height of 8 mm
The device is powered by a lithium battery
Counter inputs: solid state (4 → 30 Vdc) or voltage (10 → 260 Vac)
Reset on panel or external with inhibition option
Backlit model available
Counting directions can be selected with input
Accessories for 50 x 25 mm cut-out
The device is powered by a lithium battery
Counter inputs: solid state (4 → 30 Vdc) or voltage (10 → 260 Vac)
Reset on panel or external with inhibition option
Backlit model available
Counting directions can be selected with input
Accessories for 50 x 25 mm cut-out
Approvals
UL, CE
