Crouzet CTR24 Counter, 8 Digit LCD, 30 V dc, 260 V ac | 87622061

Name: Crouzet CTR24 Counter, 8 Digit LCD, 30 V dc, 260 V ac | 87622061
SKU: 4759-527
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 3 pcs

Mfr. Part No: 87622061

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 4759-527 Categories: Counter ICs, Crouzet

Description

Specifications

Attribute	Value
Brand	Crouzet
Supply Voltage	30 V dc, 260 V ac
Count Mode	Impulses
Display Type	LCD
Input Type	Transistor
Function	Counter
Connection Type	Screw
Reset Method	Manual, Signal
Number of Digits	8
Mounting Type	Panel Mount
Output / Interface	Transistor
Digit Height	8 mm
Display Range	-9999999 → 99999999
Maximum Operating Temperature	+60°C
Series	CTR24
Minimum Operating Temperature	-10°C
Measurement Range	-9999999 → 99999999
Weight	50g

Product Details

Crouzet Digital Counter

The Crouzet CTR24 series digital counter is an impulse, panel mounted device powered by an internal lithium battery device. This counter has a transistor input and output. It also has an 8-digit LCD display and that display rating ranges between -9999999 and +99999999. This counter supply voltage rating ranges between 4VDC and 30VDC.

Features and Benefits

Non-backlit
Reset on panel or external with inhibition option
Counting directions can be selected with input
Accessories for 50mm x 25mm cut-out
Panel cut out dimensions are 45mm x 22.2mm
Plug-in screw terminal connection
Operating temperature ranges between -10°C and 60°C
