Crouzet CTR48 Counter, 6 Digit LCD, 40kHz, 24 V ac | 87621112

Name: Crouzet CTR48 Counter, 6 Digit LCD, 40kHz, 24 V ac | 87621112
SKU: 9739-527
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 13 pcs

Mfr. Part No: 87621112

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 9739-527 Categories: Counter ICs, Crouzet

Description

Specifications

Attribute	Value
Brand	Crouzet
Supply Voltage	24 V ac
Count Mode	Hours
Display Type	LCD
Function	Counter
Input Type	Voltage
Connection Type	Screw
Reset Method	Manual, Signal
Number of Digits	6
Mounting Type	Panel Mount
Output / Interface	Relay
Count Direction	Directional, Phase, Up
Digit Height	9 mm
Backlighting	Yes
Maximum Count Frequency	40kHz
Display Range	-999999 → 999999
Measurement Range	-999999 → 999999
Maximum Operating Temperature	+65°C
Maximum Temperature	+65°C
Minimum Operating Temperature	-20°C
Series	CTR48
Weight	250g

Product Details

Single/Dual Preset Multifunction LCD Counters – CTR48

Counter, tachometer, chronometer, multi-totaliser, batch counter, preselection totaliser
Maximum input frequency 40 KHz
Simple parameter setting, configuration using text menus
Easy modification of presets
Scaling factor
5 A changeover relay and solid state output
Removable connectors
Backlit LCD display (orange): 2 lines, 6 digits or multicoloured display (green-red)
IP65 sealed panel protection
Option of locking the keypad, completely or partially (preset, programming)
Accessories include 72 x 72, 55 x 55 cut-out or a DIN rail adaptor
