Specifications
| Attribute | Value |
|---|---|
| Brand | Crouzet |
| Actuator Type | Plunger |
| Terminal Type | Solder |
| Contact Current Rating | 100 mA @ 250 V ac |
| Contact Configuration | SP-CO |
| Operating Force | 0.6 N |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | +125°C |
| Switch Housing | V4 Housing |
| Contact Material | Silver Nickel |
| Case Material | PET |
| Mechanical Life | 3 x 10^7Operations |
| Release Force | 0.1N |
| Operating Temperature Range | -20 → +125°C |
Product Details
V4 Subminiature Microswitches DIN 41635 B
– standard inverter 5 A / 250 VAC
– low-level inverter: 0.1 A.
Choice of operation accessories (available separately): levers (flat or with rollers) are proposed in two lengths with two possible mounting positions on the microswitch.
Approvals
