Crouzet Pneumatic Timer 8 bar max | 81503720
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: 81503720
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Crouzet |
| Product Type | Pneumatic Timer |
| Hazardous Area Certification | ATEX |
| Mount Type | DIN Rail |
| Minimum Operating Pressure | 2bar |
| Maximum Operating Pressure | 8 bar |
| Minimum Operating Temperature | -5°C |
| Maximum Operating Temperature | 50°C |
| Standards/Approvals | NFE 49100 |
| Depth | 7mm |
Product Details
Crouzet Pneumatic Timer
The Crouzet 81 series pneumatic adjustable positive time delay module requires operating pressure ranging between 2bar and 8bar. This timer has a counting range from 0.1 seconds to 30 seconds. On the application of a pilot signal, the reservoir starts to fill via the flow restrictor. After the set time delay the relay is operated and an output is given. This timer will not reset until the pilot signal is removed.
Features and Benefits
Orifice diameter is 2.7mm
Flow rate at 6bar is 170NL/minute
Mechanical operating life is >10^7
Operating temperature ranging between -5°C and 50°C
Certifications
ANSI/ESD S20.20:2014
BS EN 61340-5-1:2007
