Specifications
| Attribute | Value |
|---|---|
| Brand | Druck |
| Battery Type | Lithium-ion |
| Product Type | Pressure Calibrator |
| Maximum Pressure Measurement | 35bar |
| Minimum Pressure Measurement | 0bar |
| Accuracy | 0.025 % FS |
| Resolution | 0.03 % |
| Pressure Port Type | Gauge/Pseudo Absolute |
| Data Logging | Yes |
| Model Number | DPI610E |
| Intrinsically Safe | Yes |
| Current Loop Measurement | Yes |
| Display Type | LCD |
| Leak Testing | Yes |
| Power Source | Lithium-ion Battery |
| Minimum Operating Temperature | -10°C |
| Weight | 3600g |
| Maximum Operating Temperature | 50°C |
| Height | 180mm |
| Standards/Approvals | BS EN 613261:2013, BS EN 610101:2010, CE, UKCA |
| Width | 150 mm |
| Length | 35mm |
| Hazardous Area Certification | IECEx, UKEX, ATEX |
| Calibrated | RSCAL |
| Plug Type | USB |
Product Details
Druck Pressure Calibrator, Current Loop Measurement, 350mm Length – DPI610E-SPC-14G-UO -BO
Features & Benefits
Applications
Can this device handle a pressure range from vacuum to 35 bar?
Is the DPI610E suitable for hazardous environments?
Does the DPI610E offer HART communication features?
Note
What began in 1972 as a small business in Leicester, UK, Druck has grown into a global pressure-measurement business recognised as a world leader, delivering high quality piezo-resistive pressure sensors and test and calibration instruments to a wide range of applications for customers across the globe.
Druck is one of the only organisations to control the whole manufacturing process from silicon to final product. All products are high-quality, developed from the in-house (UK), raw processing of silicon to delivering the final product.
With Druck, you can be sure of quality, accuracy and reliability. We are Druck. We deliver peace of mind.
