EA Elektro-Automatik Bench Power Supply 360 V, 1-Output 30 A 3 kW | EA-PS 9360-30 1U

The EA Elektro-Automatik laboratory bench power supply has a power rating of 3kW. It is microprocessor controlled and USB-programmable single-channel power supply which provides a fully flexible ‘auto-ranging’ output. Enabling them to work with either a higher voltage or a higher current within the stipulated U/I/P rating. These power supplies are equipped with a dot Matrix LC display, with multiple functions such as memory and up to 5 digit display resolution and provides for a highly stable and low ripple output condition with a fast dynamic response. The power supply comes with “on-board” three-channel isolated Interface (analogue 0-5V/0-10V, USB and Ethernet). It has output voltage ranging between 0V to 360V and an output current rating ranging between 0A to 30A.

Inclusions:

Power cord, user manual (English/German).

Chassis TOP and bottom closed

Flexible, power regulated output stage

high-efficiency up to 93%

Operating temperature ranging between 0°C and 50°C

Photovoltaic array simulation

SCPI command language supported

Share bus support of parallel connections

Temperature controlled fans for cooling

USB and Ethernet port integrated

Various protection circuits (OVP, OCP, OTP)

Auto ranging output

Microprocessor controlled

Educational institutions

Industrial applications

Laboratories

Production and manufacturing units

Workshops
