EA Elektro-Automatik EA-3000 B Series Digital Bench Power Supply, 0 → 300V, 5 A, 500mA, 4-Output, 150W – RS | EA-3050 B

Name: EA Elektro-Automatik EA-3000 B Series Digital Bench Power Supply, 0 → 300V, 5 A, 500mA, 4-Output, 150W - RS | EA-3050 B
SKU: 0871-282
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 14 pcs

Mfr. Part No: EA-3050 B

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 0871-282 Categories: Bench Power Supplies, EA Elektro-Automatik

Description

Specifications

Attribute	Value
Brand	EA Elektro-Automatik
Series	EA-3000 B
Model Number	EA-3050 B
Number of Outputs	4
Calibrated	RSCAL
Supply Voltage	230V ac
Output Voltage	0 → 300V
Output Current	5 A, 500mA
Power Rating	150W
Number of Displays	2
Type	Digital
Bench Power Supply Type	Adjustable Power Supply
Digital/Analogue	Digital
Output Connector	4 mm Safety Socket
Input Connector	IEC 320
Maximum Temperature	+40°C
Minimum Temperature	0°C

Product Details

EA Elektro-Automatik Digital Bench Power Supply

The EA Elektro-Automatik digital bench power supply has a power rating of 150W with 4 channels (two channels supports AC and another two supports DC). The power supply’s output voltage rating ranging between 0V to 30V and current ratings ranging between 5A to 500mA. The outputs 0 – 30VAC/DC and 0 – 300VAC/DC are adjustable and can be tapped in parallel via a rectifier and a filter that can be switched off. The values of the adjustable outputs are displayed on a large 3-digit LED voltmeters and ammeters. It ensures galvanic separation of the outputs from the mains.

Features and Benefits

100% duty cycle
3-digit displays for voltage and current
Adjustable insulated transformer
Case closed on top and bottom
Operating temperature ranging between 0°C and 40°C
Safety output sockets
