Eaton Fuse Switch Disconnector, 3-Pole, 160 A, 160 A | 1814178 DMV-160N/3
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: 1814178 DMV-160N/3
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Eaton |
| Number of Poles | 3 |
| Product Type | Fuse Switch Disconnector |
| Enclosed/Not Enclosed | Enclosed |
| Mount Type | Surface |
| Switching Voltage | 690 V |
| Terminal Type | Screw |
| Switching Current | 160 A |
| IP Rating | IP20 |
| Series | DMV |
| Minimum Operating Temperature | -25°C |
| Fuse Current | 160A |
| Switching Power | 90kW |
| Maximum Operating Temperature | 55°C |
| Auxiliary Contacts Available | Yes |
| Standards/Approvals | Lloyds EAC IEC/EN 60204 IEC/EN 60947-3 |
Product Details
The Eaton Switch disconnector is designed as a main switch and maintenance switch. The device supports a motor rating of AC-23A at 400V with a power rating (P) of 90 kW and has a rated uninterrupted current (Iu) of 160 A. Connection is facilitated through screw terminals with a drilling dimension of 6.5 mm. The switch disconnector complies with standards IEC/EN 60947, VDE 0660, and IEC/EN 60204, and adheres to IEC/EN 60947-3 specifications.
RoHS compliant
IP20 degree protection
Version as emergency stop installation
