Eaton Push Button Control Station, IP65, IP67 | GHG4118101R1827

Protect a push button with this control station from Eaton CEAG Crouse-Hinds. It reduces the risk of dirt and moisture negatively affecting the good function of a button and safeguards it against everyday wear and tear. This control station is suitable for industrial use and is widely found in factories and workshops. The enclosure is made from hardwearing thermoplastic that withstands abrasion and shock. This material also resists corrosion, making the unit compatible with harsh operating conditions. For greater safety, the unit’s plastic construction offers electrical isolation to protect operators against electric shocks. You can use this control station in explosive atmospheres as it’s certified as safe for hazardous areas.

• IP66 (ingress protection) rated housing that’s dust-tight and protected against hose-directed water and rain

• Wide operating temperature range of -20°C to +40°C for use in demanding settings

• Space-saving size with compact dimensions of 85 (L) x 85 (W) x 77.5mm (D)

• Includes a cable gland to make connection and assembly easier

This control station can house one push button, such as an emergency stop switch.

Depth: 90mm

Suitable for use in Zone 1 hazardous areas

Impact resistant thermoplastic

Ingress protection to IP67 (unless stated otherwise)

Rated voltage: contact blocks; 500V, signal lamps; 240V

Rated current: contact blocks; 16A

M20 bottom cable entry complete with cable-gland

Eaton formerly known as CEAG

II 2 G EEx e d IIC T6

PTB 00 ATEX 3117
