EMERSON – ASCO Angle Seat type Pneumatic Actuated Valve, 10 bar, Female 1 in | E290D3430SA0000

Name: EMERSON – ASCO Angle Seat type Pneumatic Actuated Valve, 10 bar, Female 1 in | E290D3430SA0000
SKU: 015-234
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 3 pcs

Mfr. Part No: E290D3430SA0000

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 015-234 Categories: EMERSON ? ASCO, Pneumatic Actuated Valves

Description

Specifications

Attribute	Value
Brand	EMERSON ? ASCO
Product Type	Pneumatic Actuated Valve
Inlet Connection Type	Threaded
Valve Type	Angle Seat
Default Valve Position	NC
Inlet Port Size	1 in
Outlet Connection Type	Threaded
Outlet Port Size	G 1
Maximum Operating Pressure	10 bar
Inlet Port Gender	Female
Outlet Port Gender	Female
Outlet Thread Standard	G
Maximum Operating Temperature	184°C
Standards/Approvals	Pressure Equipment Directive 2014/68/EU, ASME B16.5, REACH Compliant, ISO 7005, EN 1092-1, RoHS Compatible, IEC 61508, ANSI Class 150, EN ISO 13849-1, EN 558-1

Product Details

The Asco Pneumatic Valve is a 2-way, pressure-operated valve featuring a durable stainless steel body and an actuator, ideal for industrial machines and manufacturing processes. It offers high reliability, long service life, and exceptional tight shutoff, with an adjustable actuator that enables 360° access to the pilot port for ease of installation and maintenance. Certified under the Pressure Equipment Directive 2014/68/EU, EN ISO 13849-1, and IEC 61508 Standard (SIL 2), this valve also complies with Reach, RoHS, and EAC directives, making it suitable for high-safety, critical applications in diverse industries.

Modular design provides exceptional flexibility

Large piloting orifice and low hysteresis creates fast cycle times

Anti-water hammer design and back pressure resistant

High performance

Maintenance-free actuator and stuffing box

Easy and fast maintenance without the need to remove valve body from pipework
