EMERSON – AVENTICS 2-Pin, Open Cable End, 3-Pin Pneumatic Sensor, IP65, IP67, IP69K 30 V, ST6 LED Indicator | R412022870
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: R412022870
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | EMERSON ? AVENTICS |
| Product Type | Pneumatic Sensor |
| Series | ST6 |
| Output Function | NO |
| LED Indicator | Yes |
| Housing Material | Polyamide |
| Voltage | 30 V |
| For Use With | KPZ, PRA, SSI, PRE, CCI, GPC, CVI |
| IP Rating | IP65, IP67, IP69K |
| Switching Action | No |
| Measurement Principle | Reed |
| Minimum Operating Temperature | -30°C |
| Maximum Operating Temperature | 80°C |
| Standards/Approvals | CE Declaration of Conformity, cULus, RoHS |
| Hazardous Area Certification | No |
| Electrical Connection Type | 2-Pin, Open Cable End, 3-Pin |
Product Details
Aventics Pneumatic Sensor
The Aventics ST6 series 6mm T-slot reed pneumatic sensor works on the normally open operation and has a cable length of 5m. It has a yellow LED indicator light to indicate the ON/OFF status. This sensor is compatible with CCI, CVI, GPC, KPZ, PRA, PRE and SSI.
Features and Benefits
Operating temperature ranging between -30°C and 80°C
Operating voltage range is from 10VAC to 30VAC
Protected against polarity reversal
Switching current DC is 0.3A
Certifications
CE certified
cULus approved
IP65 rated
IP67 rated
