Endress+Hauser 1 Phase Surge Arrester, 7.5 kA, 600 V, DIN Rail | HAW562-AAE
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: HAW562-AAE
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Endress+Hauser |
| Product Type | Surge Arrester |
| Maximum Surge Current | 7.5kA |
| Voltage Protection Rating | 600V |
| Series | HAW562 |
| Electrical Phase | 1 |
| Mount Type | DIN Rail |
| Impulse Discharge Current | 7.5kA |
| IP Rating | IP20 |
| Standards/Approvals | EN 61643-11, B2, C3, D1, IEC 61643-21:1999-07 A2, C2, IEC 61326, IEC 61010, IEC 61643-1 |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -40°C |
Product Details
The Endress+Hauser HAW562 surge arrester for DIN rail is used to protect electronic components from being destroyed by overvoltage. It ensures that overvoltage surges which occur in signal cables (e.g. 4 to 20 mA), in communication lines (fieldbuses) and in power lines are safely passed into the ground. The functionality of the transmitter or the electronics component to be protected is not affected. Surge arresters are used to weaken residual currents from upstream lightning protection steps and to limit system-induced or -generated overvoltage surges.
Protects electronic components from being destroyed by overvoltage
Weakens residual currents from upstream lightning protection steps and limits system-induced or -generated overvoltage surges
Overvoltage surges are safely passed into the ground
The fu
