Endress+Hauser RSG35-B1A 6 Graphical Chart Recorder Current, Frequency Input, Pulse Input, RTD, Thermocouple, Voltage | RSG35-B1A
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: RSG35-B1A
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Endress+Hauser |
| Chart Type | Graphical |
| Product Type | Chart Recorder |
| Accuracy | ±0.1% oMR |
| Measurement Parameters | Current, Frequency Input, Pulse Input, RTD, Thermocouple, Voltage |
| Number of Channels | 6 |
| Model Number | RSG35-B1A |
| Standards/Approvals | IEC 60529, EN 61010 |
| Weight | 2.2kg |
| Height | 144mm |
| Width | 144 mm |
| Length | 192mm |
Product Details
Recording, visualization and monitoring of process values.
The Ecograph T RSG35 is a Universal Data Manager that records, displays and monitors all analog or digital input signals. The measured values are securely saved and limit values are monitored. On-site, the navigator enables intuitive operation. Remote configuration and operation on the PC are also possible thanks to the integrated web server – no additional software needs to be installed.
The Endress+Hausers provides a safe and complete recording and visualization of all process sequences. Demands on process monitoring and data recording are becoming more and more complex. Because every measurement value counts, the universal data manager ecograph records, visualizes and monitors all analog or digital input signals.
Low installation depth, saves space and money
Temperature monitoring in metal working
Displaying and recording of critical process parameters
Key Benefits
The recorded data is stored tamperproof in the internal memory or on a separate SD card.
Intuitive operation via the navigator (rotary/ push button) on site, or user-friendly operation at the PC via the integrated web server
Versatile with up to 12 universal inputs compatible with the most common measurement signals.
Programmable e-mail notification in event of alarms and limit violation
5.7″ TFT screen for displaying measured values in a maximum of four groups, with digital, bar graph and curve display.
