ERNI 154 9 Way Straight 2.77 mm Pitch Cable D-Sub Connector, with 4-40 UNC Female | 154039 / 154039-E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: 154039 / 154039-E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ERNI |
| Number of Contacts | 9 |
| Product Type | D-Sub Connector |
| Current | 1A |
| Orientation | Straight |
| Mount Type | Cable |
| Connector Gender | Female |
| Connector Type D | D-Sub |
| Mounting Hardware | 4-40 UNC |
| D-Sub Shell Size | 9 |
| Housing Material | Thermoplastic |
| Voltage | 100V |
| Minimum Operating Temperature | -20°C |
| Termination Type | Screw |
| Contact Gender | Female |
| Maximum Operating Temperature | 70°C |
| Standards/Approvals | No |
| Contact Material | Copper Alloy |
| Series | 154 |
| Pitch | 2.77mm |
Product Details
ERNI ERbic CAN Bus CAN Bus D-Sub Connectors
ERbic CAN Bus CAN Bus connectors with a 9 pin female D-sub connector interface. The d-sub connectors have 4-40 UNC mounting screws. For more information on these ERbic CAN Bus CAN Bus connectors please see refer to data table and manufacturers datasheet.
Erbic® bus systems D Type Connectors
Interface plug connectors from the Erbic® range have compact external dimensions and a horizontal cable connection.
The ERbic® MAX range is a slimline solution with metal housing and an axial cable exit, ideal for tough conditions with high EMC requirements.
An integrated switch, accessible from the outside, lets you switch from node to terminating modes with active termination (terminating resistance).
The switch is positioned opposite the housing to prevent accidental activation.
Models with IDC clamps are available for quick and easy connection to the swivel cord.
Approvals
UL E 87403
