ERNI DIN 41612 128 Way 2.54 mm Pitch, Type Through Hole, Type RD, Type Solder Class Class C2, 4 Row Male, Right Angle | 384850 / 384850-E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: 384850 / 384850-E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ERNI |
| Number of Contacts | 128 |
| Product Type | DIN 41612 Connector |
| Number of Rows | 4 |
| Orientation | Right Angle |
| Connector Gender | Male |
| Row Loading | A/B/C/D |
| Termination Type | Solder |
| Sub Type | RD |
| Pitch | 2.54mm |
| Mount Type | Through Hole |
| Contact Plating | Gold |
| Minimum Operating Temperature | -55°C |
| Class | Class C2 |
| Maximum Operating Temperature | 125°C |
| Contact Gender | Female |
| Standards/Approvals | No |
| Contact Material | Copper Alloy |
| Series | DIN 41612 |
| Housing Material | Polybutylene Terephthalate |
Product Details
Type E/TE/CD/RD
This range of DIN41612 / IEC 60603-2 Backplane / Board to Board / Wire to Board Connectors covers different connection variations. The design of these Backplane connectors is in accordance with DIN 41612/ IEC 60603-2 providing excellent quality and reliability. Applications for these DIN41612 / IEC 60603-2 connectors include:
Connection between plug-in cards and backplane wiring
Connection between two PCB’s arranged one above the other
As a peripheral connector for external interfaces of the wiring plane
Type E160 160 contacts in 5 rows
Type TE160 160 (inverted model) 160 contacts in 5 rows
Type CD128 128 contacts in 4 rows
Type RD128 (inverted model) 128 contacts in 4 rows
TE160
Inverted model of type E160
Type TE160 female connectors are fitted with fixing strips
Elongated mounting flange has two mounting holes within 5.08 mm grid
CD128
Solderless press fit technology
RD128
Fitted with fixing strip
Mounting flange with two mounting holes within 5.08 mm grid
Approvals
UL, CSA
