ERNI DIN 41612 160 Way 2.54 mm Pitch, Type Through Hole, Type Type E, Type Solder Class Class C2, 5 Row Female, Straight | 284313 / 284313-E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: 284313 / 284313-E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ERNI |
| Product Type | DIN 41612 Connector |
| Number of Contacts | 160 |
| Current | 5.5A |
| Number of Rows | 5 |
| Orientation | Straight |
| Connector Gender | Female |
| Row Loading | A/B/C/D/E |
| Termination Type | Solder |
| Sub Type | Type E |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Mount Type | Through Hole |
| Minimum Operating Temperature | -55°C |
| Class | Class C2 |
| Maximum Operating Temperature | 125°C |
| Contact Gender | Female |
| Standards/Approvals | No |
| Contact Material | Copper Alloy |
| Series | DIN 41612 |
| Maximum Contact Resistance | 15mΩ |
| Housing Material | Polybutylene Terephthalate |
Product Details
EN60603-2 Type B/C/D/E/F, inverted Q/R
A range of DIN 41612 / IEC 60603-2 connectors with 2.54 mm basic grid.
Indirect connection system
Use in DIN 41494 construction systems (19” technology)
Connection between plug-in cards and backplane wiring
Connection between two PCBs arranged one above the other
Connection to peripheral devices with cable housing
Transfer plug for external interfaces of the wiring plane
Note
In the descriptions: M = male connector, F = female connector
Approvals
UL, CSA
