ERNI, ERmet 2 mm Pitch Hard Metric Type A Backplane Connector, Vertical Male, 25 Column, 7 Row, 110 Way | 053007 / 5100668-1

ERmet 2.0 mm Hard Metric male connectors with a high density modular design supported by international connector standards IEC 61076-4-101. These ERmet 2.0 mm HM male connectors can support various PCB arrangements including backplane, board to board and mezzanine applications. The signal pins of these headers have 3 lengths allowing 3 levels of sequential mating in 1.5 mm increments for front or rear hot swappable applications. The contacts of these ERmet 2.0 mm HM backplane connectors have a long 2.5 mm wipe length that ensures reliable mating even in adverse conditions. These ERmet 2.0 mm HM male connectors are available with optional shielding contact rows for optimum performance. Versions are also available with location pegs for improved rigidity and polarisation on the PCB. The press fit terminations of these ERmet 2.0 mm HM backplane header connectors enable simple and secure PCB mounting. These ERmet 2.0 mm Hard Metric male connectors are available in Type A, B & C configurations and various modular widths.

Stock number 917-5251 has a type B8, stage (Hot Swap) configuration with M2 keying and a PXI slot type

High density design

Conforms to international connector standards IEC 61076-4-101

3 stage sequential mating for hot swappable applications

Long contact wipe length of 2.5 mm

Alignment and polarisation features

Shielding and PCB location peg options

Press fit terminations

These ERmet 2.0 mm Hard Metric backplane headers provide a cost effective backplane, board to board and mezzanine solution for a range of high performance high density applications. Industries include networking systems, telecommunications and high performance industrial computing where PICMG specifications apply. These ERmet 2.0 mm HM connectors have also gained widespread acceptance is the interconnect system for CompactPCI.
