ERNI ERNI MicroCon Series Vertical Surface PCB Header, 26-Contact, 2 Row, 0.8 mm Pitch Surface Mount | 294027-E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: 294027-E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ERNI |
| Number of Contacts | 26 |
| Product Type | PCB Header |
| Number of Rows | 2 |
| Sub Type | PCB Receptacle |
| Current | 2.82A |
| Pitch | 0.8mm |
| Termination Type | Surface Mount |
| Housing Material | Liquid Crystal Polymer |
| Mount Type | Surface |
| Orientation | Vertical |
| Connector System | Board-to-Board |
| Stacking Height | 8mm |
| Voltage | 500 V |
| Series | ERNI MicroCon |
| Minimum Operating Temperature | -55°C |
| Row Pitch | 1.25mm |
| Contact Plating | Gold |
| Contact Material | Copper Alloy |
| Maximum Operating Temperature | 125°C |
| Contact Gender | Female |
| Standards/Approvals | DIN EN 60068-1,IEC 60721-3-1,IEC 60664,IEC 60112,IEC 60512,RoHS compliant,UL |
Product Details
The ERNI PCB Mount Receptacle is used in board-to-board connector systems for secure electrical connections. It features a fully shrouded header design that ensures proper mating and alignment. The contact mating area is plated with gold (Au), offering excellent conductivity and corrosion resistance. This receptacle is ideal for high-reliability electronic applications.
Surface mount termination method to PCB
Vertical mount orientation
EU RoHS compliant
