ERNI Voltron Series Straight PCB PCB Header, 2 Contact(s), 6.2 mm Pitch, 1 Row, Shrouded | 524233-E
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: 524233-E
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ERNI |
| Series | Voltron |
| Product Type | PCB Header |
| Current | 6A |
| Pitch | 6.2mm |
| Number of Contacts | 2 |
| Number of Rows | 1 |
| Orientation | Straight |
| Shrouded/Unshrouded | Shrouded |
| Mount Type | PCB |
| Contact Material | Gold |
| Row Pitch | 6.2mm |
| Minimum Operating Temperature | -55°C |
| Termination Type | Crimp |
| Maximum Operating Temperature | 150°C |
| Contact Gender | Male |
| Standards/Approvals | RoHS |
| Voltage | 1000 V |
Product Details
The Erni Connector is specifically designed for use in Battery Management Systems and Battery Disconnect Units enabling accurate voltage measurement across the battery architecture and ecosystem. The connector offers multiple design features, high CTI materials and contact surfaces maximize creep and clearance. This results in high performance value of up to 1000V, strong dielectric strength and capability to use above 5000M sea level, with pollution degree 2 according to IEC 60664-1. The connector complies to LV214, LV215 and USCAR automotive standards.
Increased voltage in battery architecture
Miniaturization grade with low profile
CTI 600 materials and Au terminal contact surface
