Festo CTEU series Pneumatic Logic Controller | CTEU-PN
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: CTEU-PN
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Product Type | Pneumatic Logic Controller |
| Series | CTEU |
| Voltage | 24 V |
| Display Type | LED Display |
| Hazardous Area Certification | No |
| Number of Outputs | 8 |
| Minimum Operating Temperature | -5°C |
| Maximum Operating Temperature | 50°C |
| Depth | 91mm |
| Width | 4 mm |
| Standards/Approvals | EN 60529 (IP65/IP67), c UL us – Recognised (OL), RoHS, RCM mark, EU EMC |
| Height | 5mm |
| Connection Type | M12 x 1 |
| Suitable Medias | Liquid, Air |
Product Details
Festo Pneumatic Logic Controller – CTEU Series – CTEU-PN
This pneumatic logic controller from Festo offers an effective way to manage valves in a pneumatic system. It uses compressed air or liquid rather than electrical current as its control medium, so it’s safe to use in applications involving combustible materials. The component features a Festo-specific uniformly defined interface (I-Port) that gives you a choice of different valve terminal configurations. It has communication error, undervoltage and systems diagnostic functions. An IP67 rating means it’s waterproof and dust-proof.
• Two M12 x 1 sockets
• Cycle time of 1 ms per 1 byte of user data
• Maximum of 64-byte inputs and 64-byte outputs transmitted in a cyclic process
• Operating voltage range of 18 V DC to 30 V DC
• Maximum power supply of 4 A
• Operating temperature range of -5°C to +50°C
• Weight of 93 g
• Polycarbonate material
• Dimensions of 40 (length) x 91 (width) x 50 mm (depth)
Range Information
• The Festo range of CTEU fieldbus modules offers direct and easy networking of valve terminals and other devices via a bus connection
• The units are supplied pre-assembled and have been tested for both electrical and pneumatic function
• A valve terminal configurator is available online to assist you in selecting the most suitable valve terminal for your needs
