Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Product Type | Pneumatic Rotary Actuator |
| Shaft Type | Tempered Steel |
| Action Type | Double Acting |
| Bore Size | 16 mm |
| Series | DSL |
| Maximum Operating Pressure | 8 bar |
| Cushioning Type | Plates at Both Ends, Shock Absorber at Both Ends Elastic Cushioning Rings |
| Minimum Operating Temperature | -10°C |
| Angle of Rotation | 246° |
| Maximum Torque Rating | 0.1Nm |
| Maximum Axial Force | 102.5N |
| Maximum Operating Temperature | 60°C |
| Standards/Approvals | ISO 8573-1:2010 (7:4:4) |
| Weight | 700g |
| Port Thread Size | M5 |
