Festo DSL Series 8 bar Double Acting Action Pneumatic Rotary Actuator, 25 mm Bore, 270 ° | DSL-25-100-270-P-A-S20-KF-B
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: DSL-25-100-270-P-A-S20-KF-B
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Product Type | Pneumatic Rotary Actuator |
| Shaft Type | Rotary |
| Action Type | Double Acting |
| Bore Size | 25 mm |
| Series | DSL |
| Maximum Operating Pressure | 8 bar |
| Cushioning Type | Elastic |
| Angle of Rotation | 270° |
| Minimum Operating Temperature | -10°C |
| Maximum Torque Rating | 0.7Nm |
| Maximum Axial Force | 248N |
| Maximum Operating Temperature | 60°C |
| Weight | 1650g |
| Standards/Approvals | ISO 8573-1:2010 (7:4:4), VDMA24364-B2-L |
| Port Thread Size | M5 |
Product Details
The Festo linear unit that has elastic cushioning rings or plates at both ends. It allows position detection via proximity switch and piston rod is made up of tempered steel material.
Corrosion resistance
Double acting mode of operation
