Festo DSM Series 10 bar Double Acting Action Pneumatic Rotary Actuator, 25 mm Bore, 246 ° | DSM-25-270-P1-A-B
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: DSM-25-270-P1-A-B
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Product Type | Pneumatic Rotary Actuator |
| Action Type | Double Acting |
| Shaft Type | Steel Nickel Plated |
| Bore Size | 25 mm |
| Series | DSM |
| Maximum Operating Pressure | 10 bar |
| Cushioning Type | Elastic |
| Maximum Radial Force | 120N |
| Angle of Rotation | 246° |
| Minimum Operating Temperature | -10°C |
| Maximum Axial Force | 50N |
| Maximum Operating Temperature | 60°C |
| Standards/Approvals | ISO 8573-1:2010, RoHS, VDMA24364-B1/B2-L |
| Weight | 715g |
Product Details
Festo Series DSM Pneumatic Rotary Actuator, 25mm Bore, 246° Rotary Angle – DSM-25-270-P1-A-B, Numeric Part Number: 566207
This pneumatic rotary actuator is a robust and reliable product designed for precise motion control in various automation systems. It features a 25mm bore and a maximum rotary angle of 246°, providing versatile applications. Weighing 715 g, this actuator meets the demands of high-performance environments while maintaining compact dimensions.
Features & Benefits
• Offers double-acting functionality for efficient operations
• Designed for a maximum operating pressure of 10 bar
• Equipped with elastic cushioning rings for smooth movement
• M5 port connection ensures easy integration into existing systems
• Engineered for precise positioning in pneumatic applications
Applications
• Used in assembly automation for precise component placement
• Suitable for packaging machines to control lid
• Employed in robotic systems for accurate movement control
• Utilised in material handling systems for effective load management
• Ideal for automotive manufacturing where precision is crucial
What is the effective pressure range for optimised operation?
The actuator operates effectively at a maximum pressure of 10 bar, which ensures high performance in demanding applications.
How does the elastic cushioning enhance its functionality?
The elastic cushioning rings significantly reduce impact during motion, leading to smoother operation and extended service life.
What type of connections are compatible with this actuator?
It features an M5 port connection, which allows for quick and reliable setup in various pneumatic systems.
What weight considerations should be taken into account during installation?
Weighing 715 g, it is lightweight, making installation easy and allowing for flexible mounting options without additional structural support.
Can it be integrated with existing pneumatic systems easily?
Yes, its compact design and M5 connectivity allow for straightforward integration into pre-existing pneumatic frameworks, saving time during setup.
