Festo DSM Series 10 bar Double Acting Action Pneumatic Rotary Actuator, 63 mm Bore, 270 ° | DSM-63-270-FW-A-B
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: DSM-63-270-FW-A-B
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Product Type | Pneumatic Rotary Actuator |
| Action Type | Double Acting |
| Shaft Type | Steel Nickel Plated |
| Bore Size | 63 mm |
| Series | DSM |
| Maximum Operating Pressure | 10 bar |
| Minimum Operating Temperature | -10°C |
| Angle of Rotation | 270° |
| Maximum Torque Rating | 40Nm |
| Maximum Axial Force | 500N |
| Maximum Radial Force | 500N |
| Maximum Operating Temperature | 60°C |
| Standards/Approvals | VDMA24364-B1/B2-L, RoHS-compliant, ISO 8573-1:2010 |
| Weight | 4475g |
| Port Thread Size | 1/4 in |
Product Details
The Festo semi rotary drive, drive shaft is made up of steel nickel plated material and position detection done via proximity switch and double acting mode of operation. The design of drive is vane type.
RoHS compliant
Wrought aluminium alloy housing material
