Festo DSM Series 8 bar Double Acting Action Pneumatic Rotary Actuator, 10 mm Bore, 90 ° | DSM-10-90-P-FW
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: DSM-10-90-P-FW
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Product Type | Pneumatic Rotary Actuator |
| Action Type | Double Acting |
| Shaft Type | High Alloy Stainless Steel |
| Bore Size | 10 mm |
| Series | DSM |
| Maximum Operating Pressure | 8 bar |
| Cushioning Type | Elastic |
| Minimum Operating Temperature | 0°C |
| Maximum Torque Rating | 0.85Nm |
| Angle of Rotation | 90° |
| Maximum Operating Temperature | 60°C |
| Standards/Approvals | ISO 8573-1:2010, VDMA24364-B1/B2-L |
| Weight | 150g |
| Port Thread Size | M3 |
Product Details
The Festo semi rotary drive, drive shaft is made up of high alloy stainless steel material that without position detection and double acting mode of operation. The design of drive is vane type.
RoHS compliant
Aluminium anodised housing material
