Festo DSR Series 8 bar Double Acting Action Pneumatic Rotary Actuator, 56.5 mm Bore, 184 ° | DSR-16-180-P

Name: Festo DSR Series 8 bar Double Acting Action Pneumatic Rotary Actuator, 56.5 mm Bore, 184 ° | DSR-16-180-P
SKU: 0054-571
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 4 pcs

Mfr. Part No: DSR-16-180-P

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 0054-571 Categories: Festo, Pneumatic Rotary Actuators

Description

Specifications

Attribute	Value
Brand	Festo
Product Type	Pneumatic Rotary Actuator
Action Type	Double Acting
Connection Thread Standard	ISO 228-1, ISO 1179-1
Bore Size	56.5 mm
Series	DSR
Maximum Operating Pressure	8 bar
Cushioning Type	Flexible Cushioning Rings/Plates at Both Ends
Sub Type	Rotary Vane
Maximum Torque Rating	2Nm
Maximum Radial Force	350N
Port Gender	Female
Angle of Rotation	184°
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	60°C
Weight	310g
Standards/Approvals	RoHS
Port Thread Size	M5

Product Details

FESTO Semi Rotary Drive

The DSR series by FESTO offers a wide variety of semi-rotary drives, with a range of mounting options available. The drives have an infinitely adjustable swivel angle for reduced setup times.

Features and benefits

Any impacts are minimised by flexible plastic planes, and the adjustable stop system is separate from the rotary vane, meaning forces are absorbed by the stop blocks

The rotary drives have a double acting mode of operation

Rotary vane principle

Through-hole mounting

Nickel-plated steel drive shaft

A comprehensive range of accessories are available

Size 16

M5 pneumatic connection

NBR material seals

Operating pressure of 2 to 8 bar

Uses and applications

Semi-rotary drives are required for applications involving a turning or twisting movement. They are commonly used in industrial applications such as transferring parts and controlling valves.
