Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Product Type | Pneumatic Rotary Actuator |
| Action Type | Double Acting |
| Bore Size | 92 mm |
| Connection Thread Standard | ISO 1179-1, ISO 228-1 |
| Series | DSR |
| Maximum Operating Pressure | 8 bar |
| Sub Type | Rotary Vane |
| Cushioning Type | Flexible Cushioning Rings/Plates at Both Ends |
| Maximum Radial Force | 350N |
| Angle of Rotation | 184° |
| Minimum Operating Temperature | -10°C |
| Maximum Torque Rating | 5Nm |
| Maximum Axial Force | 120N |
| Maximum Operating Temperature | 60°C |
| Weight | 1.3kg |
| Length | 78mm |
| Height | 68.1mm |
| Standards/Approvals | RoHS |
| Width | 98 mm |
| Port Thread Size | 1/8 in G |
Product Details
Festo DSR Series Pneumatic Rotary Actuator, 92mm Bore, G 1/8 Port Connection – DSR-32-180-P
Features & Benefits
Applications
Can it handle a maximum input pressure of 1.5 bar?
Will it fit applications requiring a 92mm bore sise?
Is it compatible with G 1/8 port connections?
Can it rotate up to a 180° angle?
Will it work for semi-rotary drives and actuation systems?
