Festo EMMS Series Hybrid Stepper Motor 48 V, 0.09 Nm Torque, 1.8 °, 5 mm Shaft | EMMS-ST-28-L-S
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: EMMS-ST-28-L-S
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Sub Type | Hybrid |
| Product Type | Stepper Motor |
| Step Angle | 1.8° |
| Holding Torque | 0.09 Nm |
| Voltage | 48 V |
| Shaft Diameter | 5mm |
| Current Rating | 1.4 A |
| Shaft Length | 20mm |
| IP Rating | IP65 |
| Resistance Per Phase | 2.3Ω |
| Depth | 70mm |
| Standards/Approvals | IEC 60034 |
| Output Speed | 6000rpm |
| Series | EMMS |
Product Details
Festo EMMS-ST Series Stepper Motor, 1.8° Step Angle, 48V Supply Voltage – EMMS-ST-28-L-S, Numeric Part Number: 1451384
This hybrid stepper motor delivers exceptional performance for various automation applications. With its compact dimensions of 70mm in depth and a shaft diameter of 5mm, it ensures precise control and efficient operation. Designed for a 48V DC supply voltage, it remains functional across a wide range of environments.
Features & Benefits
• High holding torque of 0.09Nm provides enhanced operational stability
• Rated for a maximum speed of 6000r/min, ensuring quick response times
• Insulation protection class B enables reliable operation at elevated temperatures
• Low winding resistance of 2.3Ω optimises efficiency
• Protection class IP65 ensures resistance to dust and moisture
Applications
• Utilised for precise positioning in robotics
• Ideal for pick-and-place automation systems
• Suitable for CNC machinery
• Employed in 3D printers for accurate motion control
• Used in electronic assembly lines to boost productivity
Can it operate in high humidity environments?
Yes, it functions in relative humidity levels up to 85%.
Will it perform well at various temperature extremes?
Yes, it operates effectively between -10 and 50°C.
Can it handle mechanical loads effectively?
Yes, it supports axial loads up to 7N and radial loads up to 20N.
