Festo Pneumatic Compact Cylinder – 554236 25 mm Bore, 50 mm ISO 21287 Series, Double Acting Acting | ADNGF-25-50-P-A
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: ADNGF-25-50-P-A
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Series | ISO 21287 |
| Product Type | Pneumatic Compact Cylinder |
| Model Number | 554236 |
| Action Type | Double Acting |
| Bore Size | 25 mm |
| Mount Type | Through Hole |
| Cushioning Type | Flexible Cushioning Rings/Plates at Both Ends |
| Body Material | Anodised Aluminium |
| Stroke Length | 50mm |
| Maximum Operating Pressure | 10 bar |
| Rod Type | High Alloy steel |
| Piston Rod Gender | Male |
| Piston Rod Thread Size | M5 |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | 80°C |
| Weight | 191g |
| Standards/Approvals | ISO 21287, ISO8573-1:2010 (7:4:4), RoHS |
Product Details
Festo ADNGF Series Pneumatic Compact Cylinder, 50mm Stroke, 25mm Bore – ADNGF-25-50-P-A, Numeric Part Number: 554236
This pneumatic compact cylinder is tailored for efficient automation solutions, ensuring consistent performance across various applications. Its robust construction and precise specifications optimise functionality in environments requiring dependable operation. The compact design allows for straightforward integration into existing systems, making it suitable for professionals in the automation and mechanical sectors.
Features & Benefits
• Double-acting mode for versatile operation
• Elastic cushioning for gentle impact absorption
• M5 pneumatic connection for simplified installation
• Complies with ISO 21287 cylinder specifications
• Compatible with lubricated operation to extend service life
Applications
• Suitable for automation systems for manufacturing processes
• Positioning tasks in assembly lines
• Robotics for controlled movements
What type of operating medium can be used with it?
The product operates on compressed air, conforming to ISO 8573-12010 standards.
How do the cushioning features benefit the application?
The elastic cushioning minimises wear and tear by absorbing impact energy during operation.
Can it be installed in any orientation?
Yes, the mounting position is flexible, allowing for installation based on requirements.
What is the maximum temperature it can handle?
The device operates efficiently within a temperature range of -20 to 80°C.
