Festo Pneumatic Sensor Male Relative Pressure | SDE3-D10S-B-FQ4-2P-M8
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: SDE3-D10S-B-FQ4-2P-M8
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Product Type | Pneumatic Sensor |
| Accuracy | 2 %FS |
| Switch Output | 2 x PNP |
| Connection Gender | Male |
| Electrical Connection Type | Cable with Plug |
| Mount Type | Panel |
| Pressure Type | Relative Pressure |
| Analogue Output | 4-20 mA |
| Connection Thread Size | M8 |
| Minimum Set Pressure | 0bar |
| Series | SDE3 |
| Maximum Set Pressure | 10bar |
| Connection Thread Standard | EN 60947-5-2 |
| Maximum Operating Temperature | 50°C |
| Depth | 74mm |
| Height | 37mm |
| Standards/Approvals | RCM CE to EU for EMC |
| Width | 27.4 mm |
Product Details
The Festo pressure sensor SDE3-D10S-B-FQ4-2P-M8 With M8 plug version. It has authorisation RCM Mark, CE mark (see declaration of conformity) to EU directive for EMC.
Materials note (* Free of copper and PTFE, * Conforms to RoHS)
Measured variable Relative pressure
Measurement method Piezoresistive pressure sensor with display
