Festo Solenoid Valve CPV14-M1H-2X3-GLS-1/8 G 1/8, 24 V dc, G 1/8 | CPV14-M1H-2X3-GLS-1/8
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: CPV14-M1H-2X3-GLS-1/8
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Festo |
| Product Type | Solenoid Valve |
| Supply Voltage | 24 V dc |
| Inlet Port Size | G 1/8 |
| Outlet Port Size | G 1/8 |
| Series | CPV |
| Body Material | Aluminium |
| Minimum Operating Temperature | -5°C |
| Maximum Operating Pressure | 10 bar |
| Maximum Operating Temperature | 50°C |
| Standards/Approvals | EN 60068-2-6, ISO 8573-1:2010, FN 942017-4, VDMA24364-B1/B2-L |
| Hazardous Area Certification | No |
| Maximum Opening Time | 30ms |
Product Details
Festo CPV Series Solenoid Valve, G 1/8 Connection Port Thread, 24V DC – CPV14-M1H-2X3-GLS-1/8
This solenoid valve by Festo is a high-quality electrical valve designed for efficient actuation purposes. With a 24V DC voltage requirement, this valve is reliable for a range of applications in the automation and mechanical industries.
Features & Benefits
• 2×3/2-way valve with a monostable closed function
• 14 mm valve size for versatile use
• Operates at -0.09 MPa to 1 MPa pressure, suitable for various pressure environments
• Piston gate valve design for reliable performance
• IP65 degree of protection for durability in challenging conditions
Applications
• Ideal for use in pneumatic systems requiring precise control
• Suitable for applications where a closed, monostable valve function is needed
Can it handle varying pressure levels?
This solenoid valve can operate within a pressure range of -0.09 MPa to 1 MPa, making it versatile for different pressure requirements.
Will it fit standard pneumatic connections?
Yes, this valve features G1/8 pneumatic connections, which are common in many pneumatic systems.
Is it suitable for high-traffic environments?
The durable design of this solenoid valve makes it reliable for applications with high-traffic volumes, ensuring consistent performance.
