Flowline Switch-Tek Series Sump Float Level Switch Float Switch, Vertical, Polypropylene Body | LV41-7501
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: LV41-7501
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Flowline |
| Device Type | Sump Float Level Switch |
| Mounting Type | Vertical |
| Body Material | Polypropylene |
| Cable Length | 15.2m |
| Minimum Operating Temperature | 0°C |
| Maximum Operating Temperature | +50°C |
| Maximum AC Voltage | 250V |
| Maximum Current | 10 A |
| Maximum Pressure | 14.5psi |
| Series | Switch-Tek |
| Standards Met | CE |
Product Details
Flowline Sump Float Switch
The Flowline Sump float switch is a mercury-free, mechanically actuated device, intended to activate electrical components, usually pumps, to start and stop automatically. This sump float switch is perfect for simple level control of liquids for filling or draining reservoirs and tanks. Its electrical rating is 10A at 250VAC.
Features and Benefits
Float switch intended for automatic start/stop of electrical components
Submersible polypropylene body and PVC cable for corrosive liquids
Dry contact closure selectable NO or NC state via wiring selection
Compatible with counter weight and cable hanger installations
High-quality, reliable level switch
Cost-effective and easy to install
Operating temperature ranges between 0°C and 50°C
Pressure limits: 14.5psi (1bar)
Applications
Pump automation
Tank
Certifications
IP68 rated
CE certified
ANSI/ESD S20.20:2014
BS EN 61340-5-1:2007
