HARTING Coding Pin 1 Way, For Use With Crimp Inserts | 09330009954

Name: HARTING Coding Pin 1 Way, For Use With Crimp Inserts | 09330009954
SKU: 0477-248
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 10 pcs

Mfr. Part No: 09330009954

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 0477-248 Categories: HARTING, Heavy Duty Power Connector Accessories

Description

Specifications

Attribute	Value
Brand	HARTING
Product Type	Coding Pin
Gender	Female
Accessory Type	Coding Pin
Size	10B
Current	16A
Cable Entry Angle	Straight
Voltage	500 V
Colour	Red
Number of Contacts	1
For Use With	Crimp Inserts
Material	Thermoplastic
Number of Rows	1
Standards/Approvals	No

Product Details

Han E® 16A Crimp Series

Harting contact inserts have a wide range of uses. Inserts are selected according to the desired number of poles and voltage and current ratings.

Current rating 16A

Working voltage 500V

6 to 24 poles

Crimp contacts must be ordered separately – option of 1.5mm² and 2.5mm²

Han E® 16A Crimp Series

These Han E® inserts are rated at 16A. They are intended for use with hoods and housings contained within ranges 5, 6, 7, & 8. These hood and housing ranges are associated to a specific Harting ‘Size’ number identifier. See the ‘compatibility’ table for details of this relationship, and stock numbers of hoods and housings that are typical of each range.

Note

The parallel action crimp tool requires locator stock no. 114-7920

Warning

These connectors should not be mated or unmated under electrical load. Connectors of the same or different types arranged in a line should be polarised to prevent the possibility of a wrong connection.
