HARWIN, D2 2.54 mm Pitch Vertical 8 Way, Through Hole Standard Pin Open Frame DIL Socket, 1A | D2808-42
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 11 pcs
Mfr. Part No: D2808-42
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | HARWIN |
| Product Type | DIL Socket |
| Number of Contacts | 8 |
| Mount Type | Through Hole |
| Pin Type | Standard |
| Current | 1A |
| Pitch | 2.54mm |
| Voltage | 100 V ac, 150 V dc |
| Row Width | 7.62mm |
| Frame Type | Open Frame |
| Contact Plating | Gold |
| Orientation | Vertical |
| Minimum Operating Temperature | -55°C |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Standards/Approvals | No |
| Width | 10.02 mm |
| Length | 10.1mm |
| Depth | 4.2mm |
| Contact Material | Beryllium Copper Alloy |
| Series | D2 |
| Housing Material | Plastic |
Product Details
Harwin D2 Series 2.54mm IC DIP Sockets
D2 series 2.54mm IC DIP sockets with an open frame design and 7.62mm row spacing. These D2 series PCB IC DIP sockets accept leads with a diameter range of 0.41 to 0.56mm and are both end and side stackable. The female contacts of these IC DIP sockets are machined and gold plated.
