Herga Pressure Sensor SPDT (NO/NC) 0.07 bar to 2.75 bar | 6101-0008
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 13 pcs
Mfr. Part No: 6101-0008
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Herga |
| Product Type | Pressure Sensor |
| Minimum Operating Pressure | 0.07bar |
| Current | 5A |
| Contact Configuration | SPDT (NO/NC) |
| Pressure Type | Differential |
| Voltage | 250 V ac |
| Series | 2 |
| Maximum Operating Pressure | 2.75 bar |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 85°C |
| Standards/Approvals | UL, CSA, RoHS |
| Hazardous Area Certification | No |
Product Details
Sensitive – Series 2, Pressure Switch
Ratings: from 70mbar to 2.75bar
Sensitive switches for pressure and differential pressure measurement
GF polyester housing, polyurethane diaphragm, PB with gold inlay contacts
All are externally adjustable, also mountable in any orientation for a wide variety of applications
Termination type: Faston
Series 2: Adjustable snap action pressure switches, single port on pressure side, 3 port options: 5.0mm radial, 4.0mm perpendicular or 1/8 NPT brass connection – for NPT adaptors see 536-2577
Factory fitted spring for operating pressure range 0.07 to 0.27 bar.
3 additional colour coded springs are included for user selection of alternative operating pressure ranges:
Red 0.21 to 0.69 bar
Dark blue 0.62 to 1.38 bar
Yellow 1.31 to 2.75 bar
Approvals
UL and CSA certified
