Hirose DF12 Series Straight Surface PCB Header, 40 Contact(s), 0.5 mm Pitch, 2 Row, Shrouded | DF12E(4.0)-40DP-0.5V(81)
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 5 pcs
Mfr. Part No: DF12E(4.0)-40DP-0.5V(81)
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Hirose |
| Product Type | PCB Header |
| Series | DF12 |
| Pitch | 0.5mm |
| Current | 300mA |
| Housing Material | Polyamide |
| Number of Contacts | 40 |
| Number of Rows | 2 |
| Orientation | Straight |
| Shrouded/Unshrouded | Shrouded |
| Mount Type | Surface |
| Connector System | Board-to-Board |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Row Pitch | 0.5mm |
| Termination Type | Solder |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 125°C |
| Contact Gender | Male |
| Standards/Approvals | No |
| Voltage | 50 V |
Product Details
0.5mm Hirose SMT Board to Board Header – DF12E Series
DF12 series straight, SMT mounting, ultra-miniature board to board, double row pin header connectors with a 0.5mm contact pitch available with a variety of stacking heights. These 0.5mm PCB mount double row pin header connectors have a UL94V-0 polyamide body and gold plated contacts.
These DF12E SMT board to board header connectors have neither metal fittings or bosses.
DF12E SMT Header and Receptacle connector mated stacking heights:
DF12(3.0)-xxxx-xxxx have a stacking height of 3mm
DF12(3.5)-xxxx-xxxx have a stacking height of 3.5mm
DF12(4.0)-xxxx-xxxx have a stacking height of 4.0mm
DF12(5.0)-xxxx-xxxx have a stacking height of 5.0mm
If no figure in brackets is quoted then the stacking height will be 3.5 to 5.0mm.
Applications:
• Mobile phone
• LCD
• Note PC
