Hirose, DM3 8 Way Right Angle Hinged MicroSD Memory Card Connector, Solder | DM3CS-SF

Name: Hirose, DM3 8 Way Right Angle Hinged MicroSD Memory Card Connector, Solder | DM3CS-SF
SKU: 7876-277
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 9 pcs

Mfr. Part No: DM3CS-SF

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 7876-277 Categories: Hirose, Memory Card Connectors, USB

Description

Specifications

Attribute	Value
Brand	Hirose
Card Type	MicroSD
Product Type	Memory Card Connector
Insertion/Removal Method	Hinged
Gender	Female
Number of Contacts	8
Number of Rows	1
Pitch	1.1mm
Orientation	Right Angle
Mount Type	Surface Mount
Contact Material	Copper Alloy
Contact Plating	Gold
Termination Type	Solder
Housing Material	Liquid Crystal Polymer
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	85°C
Standards/Approvals	No
Series	DM3

Product Details

Hirose DM3 Series microSD Card Connectors

DM3 series SMT mounting microSD card connectors with small external dimensions and a strong rigid structure. These DM3 series microSD card connectors have reverse card insertion protection and a N/O card detection switch. The termination leads of these DM3 series microSD card connectors are accessible so they can be inspected and re-worked.

• Small external dimensions

• Strong, rigid construction

• Reverse card insertion protection

• 4 connection points of the metal cover to the PCB secure connection of the ground circuit providing EMI protection

• Normally Open card detection switch

• Black LCP insulator, UL94V-0

Memory Card Connectors

Note

DM3 AT* part numbers are Push-Push with an ejection mechanism and are Top board mounting (standard)
DM3 BT* part numbers are Push-Push with an ejection mechanism and are Bottom board mounting (reverse)
DM3 C & CS* part numbers are Hinge, Push-Pull with no ejection mechanism and are Top board mounting (standard)
DM3 D* part numbers are Push-Pull without an ejection mechanism and are Top board mounting (standard)
DM3xxx-SF-xxx part numbers have standard right angle SMT terminals
DM3xxx-DSF-xxx part numbers have reverse right angle SMT terminals
